Photo-eye alignment
The brackets are squared up and retightened so both eyes point straight at each other. A bracket bent by an impact, or one that vibrates loose every few weeks, gets replaced rather than nudged back.
Garage Door Sensor and Keypad Repair
When a door starts back up as soon as it nears the floor, or the keypad on the outside wall stops letting anyone in, the fault is usually in the safety sensors, the wiring or the controls rather than the motor. Fort Worth Garage Door Service traces it before anything is replaced.
- 24/7 Service
- Upfront Quotes
- All Major Brands
Signs That Need Attention
- The door closes partway, then reverses and the opener light blinks
- One of the small lights beside the door frame is off or flickering
- The keypad no longer works but the remote still does
- The wall button only moves the door while you hold it down
- A remote works at the driveway apron but not from the street
The two photo eyes sit a few inches off the floor on either side of the opening, which is exactly where a bicycle handlebar, a trash can or a stray ball tends to hit them. A knock of a few degrees is enough to break the beam, and the opener is built to refuse to close when it cannot see a clear path.
What the Service Includes
The safety reversal system is not optional equipment, so the goal is always a working sensor pair rather than a workaround. Fort Worth Garage Door Service tests the door afterwards to confirm it stops and reverses as designed.
Sensor wiring and connections
Staples driven through the wire, brittle insulation and corroded splices all break the circuit intermittently. The run from each sensor back to the opener terminals is checked end to end.
Wall control and buttons
A wall station that only works when held, or that has lost its light and lock functions, is tested against the opener before it is swapped. Sometimes the fault is the wire, not the button.
Keypad repair or replacement
Outdoor keypads take years of sun and heat. We check the battery, contacts and mounting, reset or reprogram the entry code, and fit a compatible unit if the old one is beyond help.
Remotes and vehicle buttons
Handheld remotes and in-car buttons are paired to the opener and their range is checked. Weak range can point to a remote battery, an aging receiver or interference near the opener.
Opener settings and logic board
Travel limits and force settings are confirmed, because a door that reverses can be reacting to friction rather than to a sensor. If the control board itself has failed, we explain the choice before ordering parts.
Your Repair Options
Sensors, keypads and remotes are frequently sold as a matched set with an opener, so compatibility matters more than brand loyalty. The quote names the parts, says whether they are universal or model-specific, and covers any related hardware the technician finds.
If the door also drags, rattles or sits crooked, the sensors may simply be reporting a mechanical problem. A maintenance tune-up or off-track repair can settle that, and the repair versus replacement guide is worth reading if the opener is old enough that parts are scarce.
Service is arranged by address, including Haltom City and the rest of our Fort Worth area communities.
Sensor and Keypad Questions
Why does my garage door reverse before it closes?
Nine times out of ten the photo eyes are misaligned, blocked or wired badly, and the opener is refusing to close on what it thinks is an obstruction. Sun glare on a lens and a spider web across the beam both do it too. Fort Worth Garage Door Service checks the sensors and the door's travel together.
Can I disconnect or bypass the safety sensors?
No. The reversing system is what stops a heavy door on a child, a pet or a car bumper, and bypassing it removes that protection entirely. Ask Fort Worth Garage Door Service to repair the fault instead; leave the door closed and use the manual release if you need access in the meantime.
Why did my keypad stop working?
Usually a dead battery, a code lost after a power interruption, or sun and heat damage to the keys and contacts. Reprogramming is quick when the keypad itself is sound; Fort Worth Garage Door Service confirms which it is before recommending a replacement unit.
What affects the cost of sensor or keypad repair?
Whether the fix is an alignment, a wiring repair or a new part, and whether that part is universal or specific to your opener model. Fort Worth Garage Door Service quotes the work at the property after finding the fault, so you approve the scope before anything is replaced.
